OSE-KKD: Clamp holding prism, D: 0 - 10mm

-->

Reference number: OSE-KKD-25P

Option

Compatible Optics Dimensions in mm

Option

Compatible Optics Dimensions in mm

Need more info?
Contact our expert.

Optics & Optomechanics Team
Phone: +49 8153 405-11

opticsoptomechanics@laser2000.com

Description

Compatible optics diameter [mm]: 0 - 10
Primary material: Aluminium
Finish: Black Anodized
Compatible stage: KSP-256/KDD-25C

Downloads

OSE-KKD-25P_STP.zip

Holders.zip

Compatible optics diameter [mm]: 10
Adjustment range tilt ±[mm]: 3
Adjustment range rotation ±[mm]: 3
Coarse resolution /tilt [°/rotation]: about 2.2
Coarse resolution /rotation [°/rotation]: about 0.9
Primary material: Aluminium
Finish: Black Anodized
Weight [kg]: 0.11

Downloads

OSE-KKD-25PHRO_STP.zip

OSE-KKD_PLH_PAD.pdf

Holders.zip

Compatible optics diameter [mm]: 5 - 26
Adjustment range tilt ±[mm]: 3
Adjustment range rotation ±[mm]: 3
Coarse resolution /tilt [°/rotation]: about 1.5
Coarse resolution /rotation [°/rotation]: about 2.0
Primary material: Aluminium
Finish: Black Anodized
Weight [kg]: 0.2

Downloads

OSE-KKD-40PH_STP.zip

OSE-KKD_PLH_PAD.pdf

Holders.zip

Compatible optics diameter [mm]: 5 - 26
Adjustment range tilt ±[mm]: 3
Adjustment range rotation ±[mm]: 3
Coarse resolution /tilt [°/rotation]: about 1.5
Coarse resolution /rotation [°/rotation]: about 2.0
Primary material: Aluminium
Finish: Black Anodized
Weight [kg]: 0.25

Downloads

OSE-KKD-40PHRO_STP.zip

OSE-KKD_PLH_PAD.pdf

Holders.zip

Compatible optics diameter [mm]: 10 - 32
Adjustment range tilt ±[mm]: 3
Adjustment range rotation ±[mm]: 3
Coarse resolution /tilt [°/rotation]: about 1.0
Coarse resolution /rotation [°/rotation]: about 1.7
Primary material: Aluminium
Finish: Black Anodized
Weight [kg]: 0.4

Downloads

OSE-KKD-60PH_STP.zip

OSE-KKD_PLH_PAD.pdf

Holders.zip

Compatible optics diameter [mm]: 10 - 32
Adjustment range tilt ±[mm]: 3
Adjustment range rotation ±[mm]: 3
Coarse resolution /tilt [°/rotation]: about 1.0
Coarse resolution /rotation [°/rotation]: about 1.7
Primary material: Aluminium
Finish: Black Anodized
Weight [kg]: 0.45

Downloads

OSE-KKD-60PHRO_STP.zip

OSE-KKD_PLH_PAD.pdf

Holders.zip

Compatible optics diameter [mm]: 5 - 26
Compatible stage: KDD-40PH

Downloads

OSE-KKD-40P-UU_STP.zip

Holders.zip

Compatible optics diameter [mm]: 12,7 - 35
Compatible stage: KKD-65PH

Downloads

OSE-KKD-65P-UU_STP.zip

Holders.zip
