Longpass Filters, OSE-LOPF

-->

Reference number: OSE-LOPF-25C-300

Filters are designed to divide sharply the wavelength color by transmitting the short wavelength and cutting off the long wavelength.

Transition wavelength in nm

Need more info?
Contact our expert.

Optics & Optomechanics Team
Phone: +49 8153 405-11

opticsoptomechanics@laser2000.com

Description

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 5

Wavelength [nm]: 308- 420

Transmittance [%]: > Average 85

Transition wavelength [nm]: 306

Cutoff range wavelength [nm]: 200- 300

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 350- 500

Transmittance [%]: > Average 90

Transition wavelength [nm]: 347

Cutoff range wavelength [nm]: 200- 341

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 421.5 - 900

Transmittance [%]: > Average 93

Transition wavelength [nm]: 418

Cutoff range wavelength [nm]: 270- 405

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 417- 1100

Transmittance [%]: > Average 93

Transition wavelength [nm]: 415

Cutoff range wavelength [nm]: 270- 409

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 470.7 - 900

Transmittance [%]: > Average 93

Transition wavelength [nm]: 466

Cutoff range wavelength [nm]: 270- 458

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 504.7 - 900

Transmittance [%]: > Average 93

Transition wavelength [nm]: 500

Cutoff range wavelength [nm]: 270- 488

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 503- 1100

Transmittance [%]: > Average 93

Transition wavelength [nm]: 501

Cutoff range wavelength [nm]: 270- 496

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 519- 700

Transmittance [%]: > Average 90

Transition wavelength [nm]: 515

Cutoff range wavelength [nm]: 300- 500

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 529.4 - 900

Transmittance [%]: > Average 93

Transition wavelength [nm]: 526

Cutoff range wavelength [nm]: 270- 514

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 525- 800

Transmittance [%]: > Average 90

Transition wavelength [nm]: 522

Cutoff range wavelength [nm]: 340- 515

Cutoff range optical density (average): 6

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 534- 653

Transmittance [%]: > Average 92

Transition wavelength [nm]: 530

Cutoff range wavelength [nm]: 300- 519

Cutoff range optical density (average): 6

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 546.9 - 900

Transmittance [%]: > Average 93

Transition wavelength [nm]: 542

Cutoff range wavelength [nm]: 280- 532

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 577.1 - 900

Transmittance [%]: > Average 93

Transition wavelength [nm]: 572

Cutoff range wavelength [nm]: 300- 561

Cutoff range optical density (average): 6

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 604- 1100

Transmittance [%]: > Average 93

Transition wavelength [nm]: 601

Cutoff range wavelength [nm]: 270- 593

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 660- 1200

Transmittance [%]: > Average 93

Transition wavelength [nm]: 655

Cutoff range wavelength [nm]: 300- 635

Cutoff range optical density (average): 6

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 725- 1200

Transmittance [%]: > Average 93

Transition wavelength [nm]: 723

Cutoff range wavelength [nm]: 290- 715

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 761- 850

Transmittance [%]: > Average 90

Transition wavelength [nm]: 754

Cutoff range wavelength [nm]: 300- 736

Cutoff range optical density (average): 4

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 812.1 - 1200

Transmittance [%]: > Average 93

Transition wavelength [nm]: 805

Cutoff range wavelength [nm]: 270- 785

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 815- 915

Transmittance [%]: > Average 90

Transition wavelength [nm]: 812

Cutoff range wavelength [nm]: 635- 800

Cutoff range optical density (average): 6

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 842- 935

Transmittance [%]: > Average 97

Transition wavelength [nm]: 840

Cutoff range wavelength [nm]: 790- 834

Cutoff range optical density (average): 5

Incident angle: 0°

Downloads

OSE-lopf.pdf

DOWNLOAD

LOPF.xls

DOWNLOAD

Surface Quality: 60-40

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.5

Wavelength [nm]: 1064 - 1087

Transmittance [%]: > Average 93

Transition wavelength [nm]: 1057

Cutoff range wavelength [nm]: 400- 1020

Cutoff range optical density (average): 5

Incident angle: 0°
