Description

The LT210 Series of 1x2 and 1x1 (On/Off) optical switches offer PCB mountability combined with an industry leading small footprint. The module height of 5.5mm permit dense system configuration.

  • Meets Telcordia 1073 performance and reliability standards
  • Designed to meet Telcordia 1221 performance and reliability standards
  • Insertion loss of 0.5 dB, typical
  • Repeatability of ± 0.02 dB
  • Switching Speed of 5 ms
  • Module configuration reduces fiber routing problems
  • PCB mountable
  • Operates with direct control
  • Compact size of 5.5 x 22 x 48mm




Applications

  • System redundancy
  • Add/drop
  • Route diversity
  • Signal routing and monitoring
  • Test access
  • Component testing
